THANK YOU

USE AND CARE GUIDE

6 ft. / 8 ft. / 10 ft. HIGH VELOCITY

INDOOR/COVERED OUTDOOR CEILING FAN

We appreciate the trust and condence you have placed in Commercial Electric through the purchase of this ceiling fan. We strive to

continually create quality products designed to enhance your home. Visit us online to see our full line of products available for

your home improvement needs. Thank you for choosing Commercial Electric!

1-833-HDFANS-1 / (1-833-433-2671)

HOMEDEPOT.COM

Questions, problems, missing parts? Before returning to the store,

8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday

call Commercial Electric Customer Service

Visual instruction of how to install this fan:

Visit www.homedepot.com and enter either the Item or Model number to nd

this fan and click the link of visual instruction in the product overview section.

Item #1009 847 953

1009 847 948

Model #AK366-MBK

AK366-TM

10 ft.

6 ft. 8 ft.

Item #1009 847 949

1009 847 952

Model #AK366B-MBK

AK366B-TM

Item #1009 847 950

1009 847 951

Model #AK366A-MBK

AK366A-TM

Table of Contents

Questions and Answers:

D
Derrick TerryAug 10, 2025
How to fix a noisy Commercial Electric 1009 847 948?
- S
  Shelly HoweAug 10, 2025
  To reduce fan noise, ensure all motor housing screws are snug and that the screws attaching the fan blades to the motor hub are tight. Also, check that wire nut connections are not rattling against each other or the switch housing's interior wall. Allow the fan a 24-hour 'breaking-in' period, as most noises disappear during this time. If your fan has a ceiling light kit, make sure the glassware is secured tightly and that there is a short distance from the ceiling to the canopy, without it touching the ceiling. Finally, ensure your ceiling box is secure, using rubber isolator pads between the mounting bracket and outlet box.
E
emily63Aug 18, 2025
What to do if my Commercial Electric Fan won't start?
- M
  Michael FordAug 18, 2025
  If your fan won't start, begin by checking the main and branch circuit fuses or breakers. Then, inspect the line wire connections to the fan and the switch wire connections in the switch housing. Ensure that the frequency switches on both the remote control and receiver are set to the same frequency. Try turning the AC power off, waiting 10 seconds, and then turning it back on. Finally, reset the transmitter by performing the “LEARNING PROCESS”.
J
Javier WilliamsAug 25, 2025
Why is my Commercial Electric 1009 847 948 Fan wobbling?
- R
  rrogersAug 26, 2025
  Fan wobble is often due to loose parts. First, make sure all blades and blade bracket screws are secure. After proper installation, let the ceiling fan run for 10 minutes to self-adjust. If wobbling continues, check the blade level: measure from each blade's center to a point on the ceiling, deviations should be within 1/8 inch. If deviations exceed 1/8 inch, contact Customer Service at 1-833-HDFANS-1 / (1-833-433-2671) to order complimentary replacements of your brackets. If deviations are less than 1/8 inch, call Customer Service to order a complimentary blade balancing kit.
D
David VangSep 2, 2025
Why does my Commercial Electric 1009 847 948 move backwards and forwards when turned on?
- M
  Mary AguirreSep 2, 2025
  This start-up movement is normal for DC motor fans. The partial movement is the DC motor aligning the internal magnetic poles for proper operation. This design saves electricity and allows the fan to operate much quieter than standard AC motor fans.

Commercial Electric 1009 847 948 Specifications

General

Brand	Commercial Electric
Model	1009 847 948
Type	Ceiling Fan
Blade Material	ABS
Fan Diameter (in.)	52
Blade Span	52 in.

Summary

Safety Information

Installation

Mounting Options

Instructions and warnings for securely mounting the fan to the electrical box or ceiling structure.

Assembly

Hanging the Fan

Steps for attaching the mounting bracket and hanging the fan motor assembly.

Making the Electrical Connections

Detailed steps for connecting the fan's wiring to the household electrical system and wall control.

Installing the Wall Control

Instructions for wiring and mounting the wall control unit and its cover plate.

Installing the Canopy

Attaching the Canopy Bottom Cover

Attaching the Fan Blades

Guide for attaching the fan blades to their respective blade arms and then to the motor.

Installing the Light Cover

Operation

Wall Control Operating Instructions

Learning Process

Warm/Cool Weather Operating Instructions

Troubleshooting
