THE
BZOOO
COPROCESSOR
INTERFACE
The B2000 computer implements an extended version of the
A2000's Coprocessor Slot, designed to make the swapping of main
processors under program control much more powerful and trans-
parent to the rest of the B2000 system. There are things that can be
done from the B2000 Coprocessor slot that can't be done from the
A2000's Coprocessor Slot, so this is an important consideration to
anyone designing a Coprocessor device of some kind.
Normal
68000
DMA
The
68000
supports hardware signals designed to permit a simple
Architecture
DMA protocol. This protocol allows multiple devices to take control
of the 68000's data, address, and control buses. When a device
of
some kind desires direct access to the 68000's bus,
it
asserts the /BR
(Bus Request) input of the 68000. Once /BR is asserted, the
68000
will complete whatever operation
it's
doing to the point
it
can cleanly
relinquish
its
bus. At this point,
it
will assert
its
/BG (Bus Grant) out-
put, telling the device requesting DMA that
it's
just about ready to
shut down. The requesting device then issues
IBGACK (Bus Grant Ac-
knowledge) as soon as the
68000
is completely off the bus (DTACK
and
/AS are negated). When the DMAing device is done with the bus,
it
releases IDTACK and /BR, and the
68000
will then release /BG.
Where the
68000
DMA
The above protocol, as implemented in the
68000,
is
sufficient for
P~O~OCO~
Fails
many types of DMA operation, especially for simple things in which
there are single DMA devices on the bus. What
this
doesn't easily ac-
count for are multiple DMA devices. While the /BR and
/BGACK in-
puts to the
68000
can be wire-0Red to support several devices,
there are
still
problems with this scheme. Should multiple devices re-
quest DMA at the same time, the
68000
will see nothing different
than if only one device is requesting DMA. While careful monitoring
of the
IBGACK by responding potential bus masters can solve some
of the problems, there are much cleaner approaches to this problem.
One such solution is implemented in the ZORRO and
A2000/B2000
Expansion Buses. Each slot on the Expansion Bus has
its
own private
Bus Request and Bus Grant. Each Bus Request signal is considered by
a priority encoding and latching circuit. The result is that if simulta-
neous Bus Requests come in from Expansion Slots, only the Slot giv-
en higher priority will actually get a Bus Grant. Any Bus Requests
that come in while another DMA is in effect are held off until the
68000's/BG line has been negated for at least one tick. this circuitry,
part of the original ZORRO specification, eliminates the problems
that can occur with various DMA devices all competing for the
Ex-
pansion and Local Buses.
