The RGB signals come from the D/A conversion unit and lead directly to the expansion port. These
signals are, however, not amplified. In addition they are weakened by the S-Video output unit.
As a result I (aim to) insert a 47 Ohm resistor to each colour signal connection. You may also reduce the
load by interrupting the signal supply to the S-Video unit. Set pin 174 of the expansion port to GND to
achieve that (174 --> u36 (4066) signal switches).
The sync signals connected to the expansion port are unbuffered. As a result you may re-synchronize
your Amiga by an external tactsource. You should at least buffer the CSync line; there is no external
synchronisation possible on this pin.
Hint: make use of an XOR gate chip. You may negate certain sync line(s) to adapt your Amiga to (old?
:-( ) multiscan-monitors (the A4000 monitor adapter box will do the same; without the possibility of
selected negation).
Written by Klaus Hegemann, posted as part of 'CD32 expansion port info' by Anders Stenkvist in
comp.sys.amiga.hardware, forwarded by Michael King.
Return to the Table of Contents
ADDRESSES
For CD32 FAQ 2000 I removed all the old addresses from the FAQ. Most of these people aren't
answering the phones anymore, websites are down, email bounces. If you have a vendor still open for
CD32 business that hopefully has a valid website and email address, please pass it along. I'll be posting
all the known sites that I know of shortly.
Company Name/Link Description Location
Centsible Software
Software, Hardware, a little bit of everything! U.S.
Return to the Table of Contents
CONTRIBUTORS TO THE FAQ
The original CD32 FAQ Part 1 | Part 2
Last Maintainer: Stuart Tomlinson
Contributors listed in the original FAQ:
