INSTRUCTIONS & DIAGRAMS
18
Please pay attention to the following parameters. Incorrect settings may reduce inverter operation eciency or cause
the inverter to stop operating.
Note: AC Pump Phase setting only valid on a 220V inverter.
2022 HPD 2200L & 3700
HSPH5500H
ID: 9792
On(Working)
14:24 07/16/19
Enter Into
Setting Menu
0 0 0 0
Verify the PW
Accelerated
XXXX
Sec of startup
AC out Phaselost
Det time 1.0 S
Det Ampere: 30%
AC Out Max
50
Frequency (Hz)
AC Output
Max Voltage
389
323~506V
AC Output
021
Maximum Ampere
AC Pump Phase
Single
Three
State Now: Single
Solar Panel
556
Vmp voltage
MPPT Work Mode
PID Automatic
Automatic MPPT
