4. Terminate the LC Fiber Optic plugs per product specifications instructions. Visit
www.commscope.com for LC Connector application, instructions, and tool kit information.
Note: Furcation tubing can be used to protect coated fiber.
Visit www.commscope.com for a variety of colors.
5. Clean and install the LC terminations into the adapter; see installation and cleaning
instructions: TECP-96-194. Store excess fiber slack on the spool, as shown in Figure 11.
6. Repeat steps 1 – 5 for all outgoing PFCs.
