Pre-assembly of Pipe Bracket by Field Installer
(BSAMNT-3/-F QTY 2 EA)
(BSAMNT-M/-MH QTY 1 EA)
CRITICAL: For initial installation
to pipe, downtilt brackets must
be configured in pre-assembly
position (fully collapsed).
M10 screw
M10 screw
Top / Middle Mount Installations
BSAMNT-3/-M/-MH
1
2
11
14
8910
11
13
12
1
1098
M10 screw
WARNING : LOOSENING OR REMOVING BOLTS
THAT ATTACH MOUNTING PLATE TO ANTENNA
WILL VOID WARRANTY AND MAY RESULT IN
PRODUCT DAMAGE OR PERSONAL INJURY.
18
1098
11
13
12
BSAMNT-F
19
19
A
B
DETAIL A
DETAIL B
MAXIMUM TORQUE
M12 58N.m (43ft.lbs)
MAXIMUM TORQUE
M8 25N.m (18ft.lbs)
M10 40N.m (30ft.lbs)
M12 58N.m (43ft.lbs)
639840
Page 2 of 4
www.commscope.com
© 2020 CommScope, Inc. All rights reserved.
Visit our website at www.commscope.com or contact your local CommScope representative or BusinessPartner for more information.
All trademarks identified by ® or ™ are registered trademarks or trademarks, respectively, of CommScope, Inc. 639840 J (02/20)
