ComNav 1101 Autopilot
8. Setup & Sea Trials Checklist
8 - 1 SETUP & SEA TRIALS CHECKLIST
Getting Started
At the dock:
Enter STANDBY mode to:
1) Adjust LCD Screen Brightness & Contrast
2) Read Battery Voltage
Perform normal Reset or Full Reset to enter DOCKSIDE SETUP mode then:
3) Do Rudder Drive Test
4) Select Compass Type
Enter POWER STEER mode and:
5) Check Rudder Hard-over to Hard-over (HOH) time.
6) Set Rudder Travel Angle for Digital RAI.
Return to STANDBY mode:
7) Center and check external RAls (if fitted).
With the vessel underway and clear of traffic and obstacles:
Perform normal Reset to enter DOCKSIDE SETUP mode then:
8) Perform FIuxgate Compass compensation (if fitted).
Return to STANDBY mode and:
9) Set Compass Offset to match vessels steering compass (if fitted).
Enter POWER STEER mode:
I0) Check Autopilot operation in POWER STEER.
