11. Specifications
General
The Specifications for the 1101 Autopilot System define the basic capabilities and operational limits of
the equipment. These are as follows:
Operating Voltage: 10 VDC to 30 VDC
For use with 12 or 24 VDC Battery Systems
Operating Current: 400 Milliamps (minimum)
Operating Temperature Range: -15 to +60
o
C (5
o
to 140
o
F)
Heading Resolution: 0.25 Degrees
Heading Accuracy: ± 2.0 Degrees
Course Set Resolution: 1.0 Degrees
PORT/STBD Output Type: Open Collector, 3 Amps Max
Speed Control Output: 2.50 VDC for No Movement
5.00 VDC for Maximum Speed to Port
0.0 VDC for Maximum Speed to Starboard
(IOK ohm Source Impedance)
Navigation Input: NMEA 0183 (4800 BAUD):RMA, RMB, RMC, APB
APA, XTE, BOD, WBD, HSC, VBW, VHW, VTG
Navigation Output: AD-1OS (FURUNO) and the 0183 HDG sentence
Rudder Angle Indicator Output: +/- 500 microamps maximum for Full Scale Deflection
Size of Control Head
Width: 178 mm (7 inches)
Height: 92 mm (3.625 inches)
Depth: 35 mm (1.375 inches)
{38 mm (1.5 inches) required behind unit for cabling}
Weight of Control Head: 450 gm (1 lb)
Size of Signal Processing Unit
Width: 210 mm (8.25 inches)
Height: 95 mm (3.75 inches)
Depth: 57 mm (2.25 inches)
{76 mm (3 inches) required behind unit for cabling}
Weight of Signal Processing Unit: 1.8 Kg (4.0 lbs)
SPECIFICATIONS 11 - 1
