Comnet FDX60M1A-M - FDX60 1 Fiber Transceiver Illustrations

INS_FDX60_REV–
04/23/10
PAGE 2
NOTE: Remove Electrical Connector for Rack Mount Units
MULTIMODE OR SINGLE MODE
OPTICAL FIBER
BLACK
BLACK WITH WHITE STRIPE/RED
FIGURE 2 – FDX60 1 FIBER TRANSCEIVER
FIGURE 1 – FDX60 1 FIBER TRANSCEIVER
INSTALLATION AND OPERATION MANUAL FDX60(M)(S)(-M)
REAR PANELFRONT PANEL
TECH SUPPORT: 1.888.678.9427
