Chapter 2-40
Offset Description
Bit1 – UDRF, Undock request(0=inactive, 1=undock & flash LED)
Bit2 – UDRS, Undock request(0=inactive, 1=undock & solid LED)
Bit3 – EQBF, Enable Q-Buff(0=disable, 1=enable)
Bit4 – DWELL, Docked well LED(0=LED off, 1=LED on)
Bit5 – QVCCOK, Dock power ready status(0=No, 1=Yes)
Bit7 –CheckEject , (SoftEject request : 0=No 1=Yes )
A1h
DCID: Customer ID
Bit0 –DockType0, Dock on or not(0=off, 1=on)
Bit1 –DockType1, reserved
Bit4 – OS_undock OK
Bit5 – OS dock OK
Bit6 – Safe Undock OK
Bit7 –DockChange, Ultra Base had changed from docked to undock or undock to
dock (0=no, 1=yes)
A2h
Battery Learning steps.
A3h
SYS_STATUS: System indicator
Bit0 – S0LED, S0 state LED(0=LED off, 1=LED on)
Bit1 – S3LED, S3 state LED(0=LED off, 1=LED on)
Bit2 – VGAQ, VGA H/W suspend(0=VGA on, 1=VGA suspend)
Bit3 – PCMQ, PCMCIA H/W suspend(0/1=PCMCIA on/suspend )
Bit4 – PCMR, PCMCIA H/W reset (0=disable, 1=enable)
Bit5 –ADP,Ac adapter (0=offline, 1=online)
Bit6 –SYSR6(reserved)
Bit7 –SYSR7(reserved)
A4h
WAKEUP_ENABLE: Enable wake up function
Bit0 –PMEWAKE(PME Wk Enable:0=Disable, 1=Enable)
Bit1 –MDMWAKE (Modem Wk Enable:0=Disable, 1=Enable)
Bit2 - LANWAKE(LAN wakeup enable:0=Disable, 1=Enable)
Bit3-Bit7 – reserved
A5h
FANOFF_TEMP: Fan off temperature level
A6h
FANSPD1_TEMP: Fan on speed 1t
A7h
FANSPD2_TEMP: Fan on speed 2
A8h
FANSPD3_TEMP: Fan on speed 3
A9h
FANSPD4_TEMP: Fan on speed 4
AAh
FANSPD5_TEMP: Fan on speed 5
ABh
FANSPD6_TEMP: Fan on speed 6
ACh
FANSPD7_TEMP: Fan on speed 7
ADh
Temperature index
AEh
Reserved
AFh
THERMAL_STATUS
Bit0 – MODE (0=Local mode, 1=Remote mode)
Bit1 – FANSPDB0(Fan on/off parameter0)
Bit2 – FANSPDB1(Fan on/off parameter1)
Bit 2 1 ( When control by OS )
0 0 : Fan off
