2-6 Computer at a Glance
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: Jennifer Hale Saved by: Jennifer Hale Saved date: 10/07/98 3:32 PM
Part Number: 3877292-001 File name: ch02.doc
Top Components
Continued
Component Function
5
Scroll Lock light Indicates that Scroll Lock is on,
which causes the cursor to scroll
by fields rather than by lines.
6
Num Lk light Indicates that Num Lk is on and
that the embedded numeric
keypad is enabled.
7
display switch Turns off the display if the display
is closed while the computer is still
on. If warning beeps are enabled in
Computer Setup, a beep will sound
if the display is closed when the
computer is on.
8
built-in stereo speakers (2) Built-in stereo speakers.
9
MultiBay drive light Green light that indicates when a
MultiBay device is being accessed.
:
battery power light Turns on when a battery pack in
the computer is charging. Turns off
when the battery pack is fully
charged. Blinks to indicate a low
battery condition.
;
hard drive light Green light that indicates when the
hard drive is being accessed.
<
power/suspend light Turns on when power is turned on.
Turns off when power is turned off.
Flashes to indicate the computer is
in Suspend.
=
left and right pointing device
buttons
Click the left and right pointing
device buttons in conjunction with
the EasyPoint III pointing device to
initiate an action or confirm a
selection.
>
EasyPoint III pointing device Provides mouse functions with all
software that supports a Microsoft-
compatible mouse.
?
Programmable Keys Four user-programmable keys
used to quickly open an application
on your computer, bring up a
document, or emulate one of the
Microsoft Windows and Application
Logo Keys.
