Computer at a Glance 2-7
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: Jennifer Hale Saved by: Jennifer Hale Saved date: 10/07/98 3:32 PM
Part Number: 3877292-001 File name: ch02.doc
Bottom Components
Bottom Components
Component Description
1
memory expansion slot cover This cover must be removed in
order to install an optional memory
expansion board.
2
battery release latch Releases the battery pack from the
battery bay.
3
docking restraint latch recess Helps to secure the computer to
the desktop expansion base.
4
MultiBay release latch Releases a removable hard drive,
CD-ROM drive, or diskette drive
from the MultiBay.
