Battery Packs 4-11
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: Jennifer Hale Saved by: WBuoy Saved date: 10/05/98 12:58 PM
Part Number: 387792-001 File name: ch04.doc
Removing the Battery Pack
from the Battery Bay
CAUTION:
Always initiate Suspend or turn off the computer prior to
removing the battery. Removing the battery without initiating
Suspend when the system is powered on could result in data loss. If
Suspend is initiated, be sure to insert a charged battery pack within
five minutes.
1. If the computer is turned on, turn it off or press the suspend
button. If there is hard drive or diskette activity, Suspend may
not occur instantly.
2. Tilt the computer at an angle so you can see the bottom of the
computer.
3. Slide the battery release latch
1
on the bottom of the
computer.
4. Remove the battery pack
2
.
To Next Page
