7–4 Maintenance and Service Guide
Screw listing
Phillips PM2.0x6.0 screw
Where used: 2 screws that secure the audio board to the base enclosure
Where used: 1 screw that secures the right speaker to the base enclosure
Where used: 1 screw that secures the top cover to the base enclosure
Color Quantity Length Thread Head diameter
Black 4 6.0 mm 2.0 mm 5.0 mm
