Screw listing
Maintenance and Service Guide 7–5
Phillips PM2.5x6.0 captive screw
Where used:
1 Two screws that secure the hard drive cover to the computer (screws are secured by C-clips)
2 Two screws that secure the memory module cover to the computer (screws are secured by C-clips)
3 One screw that secures the WLAN cover to the computer (screw is secured by a C-clip)
Color Quantity Length Thread Head diameter
Black 5 6.0 mm 2.5 mm 5.0 mm
