Drop
(in box)
42 in (107 cm) on concrete, 16-drop
sequence
Operating system
support
Microsoft Windows 2000 (Service Pack 4 or greater), Windows XP
Home, Windows XP Professional
Approvals
UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-Tick, MIC, BG
Prufzert Mark
Ergonomic compliance
ANSI HFS 100, ISO 9241-4, and TUVGS
Kit contents
Keyboard, installation guide, warranty card, safety and comfort guide
HP PS/2 Scroll Mouse
Dimensions
3.8 x 6.3 x 11.6 cm (1.5 x 2.5 x 4.6 in)
Weight
4.44 oz (126 g)
Environmental
Operating temperature
50° to 122° F (10° to 50° C)
Non-operating
temperature
22° to 140° F (-30° to 60° C)
Operating humidity
10% to 90% (non condensing at ambient)
Non-operating humidity
20% to 80% (non condensing at ambient)
Operating shock
40 g, 6 surfaces
Non-operating shock
80 g, 6 surfaces
Operating vibration
2 g peak acceleration
Non-operating
vibration
4 g peak acceleration
Drop
(out of box)
26 in (66 cm) on carpet, 6-drop sequence
Drop
(out of box)
1 m on asphalt tile over concrete, 6-drop
sequence
Electrical
Operating voltage
5 VDC ± 10%
Power consumption
15 mA
System consumption
PS/2 mini-din connector
ESD
CE level 4, 15 kV air discharge
EMI-RFI
Conforms to FCC rules for a Class B
computing device
Microsoft
PC99 – 2001
Functionally compliant
Mechanical
Resolution
400 ± 20% DPI
Tracking speed
10 in/s (25.4 cm/s) maximum
Acceleration
100 in/s/s (2.54 m/s/s)
Switch actuation
65 g nominal peak force
Switch life
1,000,000 operations (using Hasco modified
tester)
Switch type
Low force micro-switches
Tracking mechanism
life
155 mi (250 km) at average speed of 10 in/s
Cable length
6 ft (1.8 m)
Microsoft PC99 – 2001
Mechanically compliant
Scroll wheel
Width
8 mm
Diameter
.99 in (25.2 mm)
Maximum rotation
speed
30 mm/s
Switch type
Light force micro-switch
QuickSpecs
HP Compaq dc5750 Business PC
Technical Specifications - Input/Output Devices
DA - 12546 Worldwide QuickSpecs — Version 10 — 1.30.2007
Page 30
