Compaq Deskpro EN Series Specification

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Technical Specifications
29 DA-10021-00A-018 — 07.19.2000
Compaq Deskpro EN Series
Desktop
Disk
32X Max
CD-ROM Drive
Applicable Disk
Photo-CD/Multi-session, Audio CD, CD-I, CD-ROM XA, MPEG,
MPC level 2
Note: Additional hardware required for CD-ROM XA.
Capacity
650 MB
Block Size
Mode 1: 2,048 bytes
Mode 2: 2,340, 2,336 bytes
(CD-DA): 2,352 bytes
(CD-XA): 2,328 bytes
Rotational Speed
5200 rpm
Diameter
12 cm, 8 cm
Center Hole
15 mm
Thickness
1.2 mm
Track Pitch
1.6 µm
Interface IDE
Access Time (typical)
Random
< 100 ms
Full-Stroke < 150 ms
Audio Output Level
Line-Out
0.7 V
@ 47 ohm
Headphone
0.6 V
@ 32 ohm
Data Transfer Rate
Data Transfer Rate
Sustained
150 KB/s Min (audio)
Variable
1800 to 4800 KB/s (CD)
Cache Buffer 128 KB
Start-up Time
< 7 seconds (typical); < 30 sec with multi-session
Stop Time
< 4 seconds
Laser Parameters
Type
Semiconductor Laser ConAIAs
Wave Length
780 ± 25 nm
Divergence Angle 53.5° ± 1.5°
Output Power
0.14mW @ objective lens
Operating Conditions
Temperature
41° to 113°F/5° to 45°C
Humidity
10% to 80% relative humidity
Dimensions (HxWxD) 1.69 x 5.91 x 8.2 in/4.29 x 15.01 x 20.8 cm
Weight
2.65 lbs/1.2 kg
