4–8
Maintenance and Ser
vice Guide
Remov
al and Replacement Preliminaries
T
able 4-2 lists the shielding protection provided b
y antistatic bags
and floor mats.
T
able 4-2
Static-Shielding Materials
Material
Use
V
oltage Protection Level
Antistatic plastic
Bags
1,500 V
Carbon-loaded plastic
Floor mats
7,500 V
Metallized laminate
Floor mats
5,000 V
126
128
Table of Contents
Table of Contents
4
Description
8
Models
8
Table
8
Features
54
Clearing a Password
56
Power Management
57
Notebook External Components
58
Design Overview
68
Troubleshooting
69
Computer Setup and Diagnostics Utilities
69
Using Computer Setup
70
Selecting from the File Menu
71
Selecting from the Security Menu
72
Selecting from the Advanced Menu
73
Using Compaq Diagnostics
75
Obtaining, Saving, or Printing Configuration Information
75
Obtaining, Saving, or Printing Diagnostic
76
Test Information
76
2.3 Troubleshooting Flowcharts
78
Default Chapter
78
Troubleshooting Flowcharts
78
No Power, Part 1
81
No Power, Part 3
83
No Video, Part 1
85
Nonfunctioning Docking Station
86
No os Loading from Diskette Drive
88
No os Loading from Hard Drive, Part
88
No os Loading from CD- or DVD-ROM Drive
92
No Audio, Part 2
93
Nonfunctioning Device
95
Illustrated Parts Catalog
99
Serial Number Location
99
Notebook System Major Components
100
Miscellaneous Plastics/Hardware Kit
103
Components
114
Mass Storage Devices
116
Miscellaneous
118
Removal and Replacement Preliminaries
120
Tools Required
120
Service Considerations
121
Plastic Parts
121
Cables and Connectors
121
Preventing Damage to Removable Drives
122
Preventing Electrostatic Damage
123
Packaging and Transporting Precautions
123
Workstation Precautions
124
Grounding Equipment and Methods
125
Removal and Replacement Procedures
128
Serial Number
129
Disassembly Sequence Chart
129
Preparing the Notebook for Disassembly
131
Notebook Feet
136
Memory Expansion Board
136
Mini PCI Communications Board
139
Connector Cover
142
LED Cover
143
Keyboard
145
Display
149
Top Cover
153
Speaker Assembly
158
Display Release Assembly
160
Touchpad
162
Fan
165
Processor
167
Disk Cell Real Time Clock (RTC) Battery
169
System Board
171
Modem Cable
176
Specifications
178
Connector Pin Assignments
197
B Power Cord Set Requirements
203
3-Conductor Power Cord Set
203
General Requirements
203
Country-Specific Requirements
204
Screw Listing
206
Other manuals for Compaq Evo N800c Series
Maintenance And Service Guide
181 pages
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Compaq Evo N800c Series and is the answer not in the manual?
Ask a question
