Removal and Replacement Procedures
Maintenance and Service Guide 5–35
5.14 TouchPad
1. Prepare the notebook for disassembly (Section 5.3) and
remove the following components
a. LED cover (Section 5.8)
b. Keyboard and shield (Section 5.9)
c. Display (Section 5.10)
d. Top cover (Section 5.11)
e. Speaker assembly (Section 5.12)
TouchPad and TouchButton Board
Spare Part Number Information
TouchPad
TouchButton board for Dual Point
TouchButton board for TouchPad
285258-001
285259-001
285260-001
