Compaq Evo N800c Series User Manual

5–36 Maintenance and Service Guide
Removal and Replacement Procedures
2. Remove the four PM2.0 × 4.0 screws 1 that secure the
TouchPad bracket to the top cover (Figure 5-27).
3. Disconnect the TouchPad cable 2 from the low insertion
force (LIF) connector on the TouchPad.
4. Slide the TouchPad bracket toward the back of the top
cover 3.
5. Lift the TouchPad bracket straight up 4 and remove it.
Figure 5-27. Removing the TouchPad

Compaq Evo N800c Series Specifications

General

Brand	Compaq
Model	Evo N800c Series
Category	Laptop
Language	English
