Removal and Replacement Procedures
Maintenance and Service Guide 5–19
1. Prepare the notebook for disassembly (Section 5.3).
2. Remove the LED cover (Section 5.8).
3. Lift the back edge of the keyboard 1 (Figure 5-15).
4. Slide the keyboard toward the back of the notebook 2.
5. Lift the back edge of the keyboard and swing it forward 3
until it rests on the palm rest.
Figure 5-15. Releasing the Keyboard
