Removal and Replacement Procedures
Maintenance and Service Guide 5–25
9. Remove the hinge covers from the display (Figure 5-20).
Figure 5-20. Removing the Hinge Covers
✎
The display hinge covers are included in the Miscellaneous
Plastics/Hardware Kit, spare part numbers 285261-001 and
286868-001.
✎
Install the hinge covers on the display before installing the
display on the base enclosure.
Reverse the above procedure to install the display.
