Removal and Replacement Procedures
Maintenance and Service Guide 5–43
2. Use a flat-bladed tool to release the RTC battery from its
socket 1 (Figure 5-31).
3. Remove the RTC battery 2.
Figure 5-31. Removing the Disk Cell RTC Battery
✎
When replacing an RTC battery, insert the battery with the
“+” sign facing up.
