Compaq Evo N800c Series

6–6 Maintenance and Service Guide
Specifications
Table 6-5
14.1-inch XGA, TFT Display
Dimensions
Height
Width
Diagonal
20.50 mm
21.49 mm
35.81 mm
11.22 in
8.46 in
14.1 in
Number of colors up to 16.8 million
Contrast ratio 150:1
Brightness 120+ nits typical
Pixel resolution
Pitch
Format
Configuration
0.264 × 0.264 mm
1024 × 768
RGB vertical stripe
Backlight Edge lit
Character display 80 × 25
Total power
consumption
4.2 W
