Screw Listing
Maintenance and Service Guide C–3
Figure C-2. Phillips M3.0 × 4.0 Screw Locations
Table C-1
Phillips M3.0 × 4.0 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Black 3 4.0 mm 3.0 mm 5.0 mm
Where used:
Two screws that secure the hard drive bezel to the hard drive
(documented in Section 5.3)
