Compaq Evo N800c Series

C–10 Maintenance and Service Guide
Screw Listing
Figure C-9. Phillips M2.0 × 4.0 Screw Locations
Table C-4
Phillips M2.0 × 4.0 Screw (Continued)
Color Qty. Length Thread
Head
Width
Gold 14 4.0 mm 2.0 mm 4.0 mm
Where used:
1 Two screws that secure the top cover to the base enclosure near the fan
assembly (documented in Section 5.11)
2 Two screws that secure the top cover to the base enclosure through the rear
panel (documented in Section 5.11)
