Screw Listing
Maintenance and Service Guide C–15
Figure C-14. Phillips M2.0 × 8.0 Screw Locations
Table C-6
Phillips M2.0 × 8.0 Screw
Color Qty. Length Thread
Head
Width
Black 15 8.0 mm 2.0 mm 4.0 mm
Where used:
Nine screws that secure the top cover to the base enclosure through the bottom
of the notebook (documented in Section 5.11)
