C266 2401-000603 C-AL 1uF,20%,50V,GP,TP,5x11,5
C267 2202-002148 C-CERAMIC,MLC-RADIAL 0.68NF,2%,50V,NP0,TP,5.1X3.2X6.4MM,5
C268 2401-000480 C-AL 10uF,20%,50V,GP,TP,5x11,5
C269 2202-000654 C-CERAMIC,MLC-RADIAL 100nF,10%,50V,X7R,TP,5.1x6.6,5
C270 2401-000050 C-AL 10uF,20%,16V,GP,TP,5x11,2.5
C271 2305-001041 C-FILM,MPEF 220nF,5%,63V,TP,7.5x4.5x13.5,5
C272 2201-000017 C-CERAMIC,DISC 1nF,10%,50V,Y5P,TP,4x3.5,5
C273 2301-000005 C-FILM,PEF 33nF,5%,100V,TP,5.8x12.5x3,5
C274 2401-003080 C-AL 3.3UF,20%,50V,BP,TP,5X11,2.5
C275 2202-002008 C-CERAMIC,MLC-AXIAL 10nF,+80-20%,50V,Y5V,TP,2.3X3.
C276 2401-000042 C-AL 100uF,20%,16V,GP,TP,6.3x7,5
C277 2202-002008 C-CERAMIC,MLC-AXIAL 10nF,+80-20%,50V,Y5V,TP,2.3X3.
C278 2401-003473 C-AL 680UF,20%,16V,GP,TP,10X12.5MM,5
C279 2401-000480 C-AL 10uF,20%,50V,GP,TP,5x11,5
C280 2201-000215 C-CERAMIC,DISC 120pF,5%,50V,CH,TP,9.5x3,5
C282 2301-000168 C-FILM,PEF 150nF,5%,100V,TP,11.5x19mm,7.5
C283 2401-000050 C-AL 10uF,20%,16V,GP,TP,5x11,2.5
C284 2305-000412 C-FILM,MPEF 470nF,5%,63V,TP,-,5mm
C285 2401-000597 C-AL 1uF,20%,50V,GP,TP,4x7mm,1.5mm
C301 2401-000142 C-AL 1000uF,20%,16V,WT,TP,10x20,5
C302 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,TP,2.3X3
C305 2301-000010 C-FILM,PEF 100nF,5%,100V,TP,11.5x12.5mm,5
C306 2401-000852 C-AL 220uF,20%,35V,GP,TP,8x11.5mm,5
C307 2301-000010 C-FILM,PEF 100nF,5%,100V,TP,11.5x12.5mm,5
C308 2305-000237 C-FILM,MPEF 1uF,5%,63V,TP,7.5x15.5mm,5mm
C309 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,TP,2.3X3
C310 2301-000013 C-FILM,PEF 4.7nF,5%,100V,TP,10.5x12.5x6.5
C311 2401-000039 C-AL 1000uF,20%,16V,GP,TP,10x16,5
C312 2401-000597 C-AL 1uF,20%,50V,GP,TP,4x7mm,1.5mm
C313 2301-000013 C-FILM,PEF 4.7nF,5%,100V,TP,10.5x12.5x6.5
C401 2301-000188 C-FILM,PEF 1nF,5%,100V,TP,10.5x12.5x6.5,5
C402 2401-000046 C-AL 10uF,20%,250V,GP,TP,10x20,5
C403 2305-000624 C-FILM,MPEF 330nF,10%,100V,TP,-,5mm
C406 2401-000049 C-AL 47uF,20%,100V,WT,TP,10x16,5
C407 2201-000291 C-CERAMIC,DISC 1nF,10%,500V,Y5P,TP,8.5x5MM,5
C408 2305-000624 C-FILM,MPEF 330nF,10%,100V,TP,-,5mm
C409 2305-000624 C-FILM,MPEF 330nF,10%,100V,TP,-,5mm
C410 2301-000020 C-FILM,PEF 27nF,5%,100V,TP,7.3x4x12.5mm,5
C411 2301-001304 C-FILM,PPF 1.5NF,5%,2.5KV,TP,23X17X11MM,7.5
C412 2301-001169 C-FILM,PPF 1.8nF,5%,2.5KV,TP,22.5x20x12.5
C418 2301-000102 C-FILM,PEF 1.2nF,5%,100V,TP,5.4x10mm,5mm
C419 2201-000131 C-CERAMIC,DISC 100pF,10%,2KV,Y5P,TP,8x6,5
C420 2401-000025 C-AL 100uF,20%,16V,GP,TP,6.3x11,5
C421 2401-000613 C-AL 1uF,20%,50V,WT,TP,5x11,5
C422 2301-000174 C-FILM,PEF 15nF,5%,100V,TP,7.2x4.0x7.5mm,
C423 2202-000561 C-CERAMIC,MLC-RADIAL 680pF,5%,50V,NPO,TP,5.1x3.2,5.
C424 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,TP,2.3X3
!
!
7 Electrical Parts List
7-2 PG17**/PG19**/PG21**
Loc. No. Code No. Description Specification Remarks
