C425 2202-002008 C-CERAMIC,MLC-AXIAL 10nF,+80-20%,50V,Y5V,TP,2.3X3.
C426 2202-000470 C-CERAMIC,MLC-RADIAL 330pF,5%,100V,NPO,TP,5.1x5.1x3
C427 2303-000011 C-FILM,PPF 1nF,5%,100V,TP,14x11.5mm,7.5mm
C428 2301-000020 C-FILM,PEF 27nF,5%,100V,TP,7.3x4x12.5mm,5
C429 2301-000284 C-FILM,PEF 47nF,5%,100V,TP,8.5x12.5mm,5mm
C430 2401-000480 C-AL 10uF,20%,50V,GP,TP,5x11,5
C431 2202-002008 C-CERAMIC,MLC-AXIAL 10nF,+80-20%,50V,Y5V,TP,2.3X3.
C432 2201-000019 C-CERAMIC,DISC 10nF,+80-20%,500V,Y5V,TP,13.5x
C451 2301-001249 C-FILM,MPPF 68nF,5%,400V,TP,19x7x15mm,7.5
C452 2301-001259 C-FILM,MPPF 100nF,5%,400V,TP,19x8x16,7.5mm
C453 2306-000179 C-FILM,MPPF 300nF,5%,250V,TP,20x18.5x10.5,
C454 2306-000234 C-FILM,MPPF 560nF,5%,250V,BK,26x20x13,20
C455 2306-000147 C-FILM,MPPF 1uF,5%,250V,BK,26x24x15,22.5mm
C456 2306-000131 C-FILM,MPPF 150nF,5%,250V,TP,19x16x7.5,7.5
C457 2301-001249 C-FILM,MPPF 68nF,5%,400V,TP,19x7x15mm,7.5
C459 2401-003080 C-AL 3.3UF,20%,50V,BP,TP,5X11,2.5
C501 2301-001027 C-FILM,PEF 15nF,10%,250V,TP,9.5x12x4.5,5m
C502 2201-000119 C-CERAMIC,DISC 100nF,+80-20%,50V,Y5V,TP,8x3.5
C503 2401-000480 C-AL 10uF,20%,50V,GP,TP,5x11,5
C504 2401-001576 C-AL 47uF,20%,50V,GP,TP,8x11.5,5
C505 2401-000037 C-AL 470uF,20%,16V,GP,TP,8x11.5,5
C521 2301-000294 C-FILM,PEF 56nF,5%,100V,TP,9.5x12.5mm,5mm
C522 2301-000148 C-FILM,PEF 10nF,5%,100V,TP,7x3.2x7mm,5mm
C523 2401-000292 C-AL 100uF,20%,16V,WT,TP,8x11.5mm,5
C524 2201-000163 C-CERAMIC,DISC 10nF,79.8,50V,Y5V,TP,6.5x5mm,2
C525 2305-001041 C-FILM,MPEF 220nF,5%,63V,TP,7.5x4.5x13.5,5
C526 2201-000119 C-CERAMIC,DISC 100nF,+80-20%,50V,Y5V,TP,8x3.5
C527 2401-001195 C-AL 33uF,20%,50V,GP,TP,6.3x11,5
C528 2401-001576 C-AL 47uF,20%,50V,GP,TP,8x11.5,5
C530 2201-000469 C-CERAMIC,DISC 330pF,10%,500V,Y5P,TP,6x4,5
C531 2303-000147 C-FILM,PPF 1NF,5%,2KV,TP,23X13X8MM,7.5
C532 2401-000638 C-AL 2.2uF,20%,350V,WT,TP,10x12.5mm
C533 2201-000732 C-CERAMIC,DISC 680pF,10%,1KV,Y5P,TP,6.3x4,5
C534 2401-001576 C-AL 47uF,20%,50V,GP,TP,8x11.5,5
C535 2401-000771 C-AL 220uF,20%,100V,WT,TP,16x25,7.5
C536 2401-003080 C-AL 3.3UF,20%,50V,BP,TP,5X11,2.5
C537 2401-000638 C-AL 2.2uF,20%,350V,WT,TP,10x12.5mm
C538 2305-000665 C-FILM,MPEF 100nF,5%,63V,TP,7.5x4.0x5.0mm,
C539 2401-000649 C-AL 2.2uF,20%,50V,BP,TP,5x11,5
C540 2201-000732 C-CERAMIC,DISC 680pF,10%,1KV,Y5P,TP,6.3x4,5
C551 2401-000043 C-AL 1uF,20%,160V,GP,TP,6.3x11,5
C552 2305-000004 C-FILM,MPEF 220nF,10%,100V,TP,12.7x16,5mm
C555 2305-000004 C-FILM,MPEF 220nF,10%,100V,TP,12.7x16,5mm
C556 2201-000285 C-CERAMIC,DISC 1nF,10%,1KV,Y5P,TP,10x5,5
C557 2201-000012 C-CERAMIC,DISC 220pF,10%,1KV,Y5P,TP,6x5,5
C558 2201-000144 C-CERAMIC,DISC 100pF,5%,50V,CH,TP,8x3,5
C603 2201-000019 C-CERAMIC,DISC 10nF,+80-20%,500V,Y5V,TP,13.5x
!
7 Electrical Parts List
PG17**/PG19**/PG21** 7-3
Loc. No. Code No. Description Specification Remarks
