R665 2004-000964 R-METAL 470Kohm,1%,1/4W,AA,TP,2.4x6.4m
R666 2004-000964 R-METAL 470Kohm,1%,1/4W,AA,TP,2.4x6.4m
R667 2004-001211 R-METAL 7.5Kohm,1%,1/4W,AA,TP,2.4x6.4m
R668 2001-000734 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R669 2001-000793 R-CARBON 47OHM,5%,1/8W,AA,TP,1.8X3.2MM
RL601 3501-001111 RELAY-POWER 12Vdc,250mW,5A,1FormA,15mS,5mS
SK521 4715-000001 SURGE ABSORBER 1KV,+50-10%
T401 BH26-00041A TRANS-HOR.DRIVE 2.7MH,8P,EI-2519,PL3,EI-2519
T402 BH26-00040A TRANS-HOR.PULSE 1.5MH,10P,EI-3026,PL3,50UH,EI-3026
T403 BH26-00002A TRANS-H.GATE 520UH,5P,EI-1614,SB-5S,520UH/520UH
T501 BH26-00051A TRANS-FBT 80.4UH,14P,HV22UR,HV22U,FEA875
T502 BH26-00056A TRANS-FOCUS 3.8MH MIN,10P,SB-5S,EI-2218,SB-5S,3
T601 BH26-00039A TRANS-POWER 150UH,18P,EER4042,PL3,6.0UH,ER4042
T602 BH26-30302S TRANS-SYNC. 3-1(250UH),SB-5S,UU1116,3
T661 BH26-00042A TRANS 2.5MH,8P,EI-1916,PL3,150UH
TCO BH71-40300A PIN-HINGE BRASS,D2.36,SN,HEAT/SINK
TH601 1404-001076 THERMISTOR-NTC 8ohm,15%,17mW/C,TP
VR401 2103-001049 VR-SEMI 100ohm,30%,1/5W,SIDE
VR501 2103-001080 VR-SEMI 100KOHM,25%,0.3W,SIDE
X201 2801-000006 CRYSTAL-UNIT 12MHz,50ppm,28-AAM,S,35ohm,BK
ZD241 0403-000361 DIODE-ZENER UZ6.2BSB,6.2V,5.99-6.24V,500mW
ZD242 0403-000361 DIODE-ZENER UZ6.2BSB,6.2V,5.99-6.24V,500mW
ZD243 0403-000361 DIODE-ZENER UZ6.2BSB,6.2V,5.99-6.24V,500mW
ZD252 0403-000361 DIODE-ZENER UZ6.2BSB,6.2V,5.99-6.24V,500mW
ZD260 0403-000509 DIODE-ZENER MTZJ5.6B,5.6V,5.45-5.73V,500mW
ZD501 0403-000355 DIODE-ZENER UZ5.1BSB,5.1V,4.97-5.18V,500mW
ZD601 0403-000753 DIODE-ZENER MTZJ27D,27V,26.29-27.64V,500mW
ZD602 0403-001068 DIODE-ZENER UZ4.7BSA,4.7V,4.47-4.65V,500mW
ZD661 0403-000367 DIODE-ZENER UZ7.5BSC,7.5V,7.33-7.64V,500mW
!
!
!
!
!
!
!
!
7 Electrical Parts List
PG17**/PG19**/PG21** 7-15
Loc. No. Code No. Description Specification Remarks
