BD101 3301-000011 CORE-FERRITE BEAD AA,3.5x1.0x5.7mm,1500,2375G
BD105 3301-000011 CORE-FERRITE BEAD AA,3.5x1.0x5.7mm,1500,2375G
BD106 3301-000011 CORE-FERRITE BEAD AA,3.5x1.0x5.7mm,1500,2375G
BD151 3301-000011 CORE-FERRITE BEAD AA,3.5x1.0x5.7mm,1500,2375G
BD155 3301-000011 CORE-FERRITE BEAD AA,3.5x1.0x5.7mm,1500,2375G
BD181 3301-000011 CORE-FERRITE BEAD AA,3.5x1.0x5.7mm,1500,2375G
BD182 3301-000011 CORE-FERRITE BEAD AA,3.5x1.0x5.7mm,1500,2375G
C101 2401-003224 C-AL 470uF,20%,16V,WT,TP,8X11.5,5mm
C102 2202-000319 C-CERAMIC,MLC-RADIAL 100nF,10%,100V,X7R,TP,5.1x3.2x
C103 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,TP,2.3X3
C104 2401-003224 C-AL 470uF,20%,16V,WT,TP,8X11.5,5mm
C105 2201-000119 C-CERAMIC,DISC 100nF,+80-20%,50V,Y5V,TP,8x3.5
C106 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,TP,2.3X3
C107 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,TP,2.3X3
C108 2401-003224 C-AL 470uF,20%,16V,WT,TP,8X11.5,5mm
C109 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,TP,2.3X3
C110 2401-003080 C-AL 3.3UF,20%,50V,BP,TP,5X11,2.5
C111 2202-000319 C-CERAMIC,MLC-RADIAL 100nF,10%,100V,X7R,TP,5.1x3.2x
C112 2401-003484 C-AL 10uF,20%,100V,LZ,TP,6.3X11,5
C113 2401-000393 C-AL 10uF,20%,100V,WT,TP,8x11.5,5
C114 2401-000393 C-AL 10uF,20%,100V,WT,TP,8x11.5,5
C115 2401-000031 C-AL 47uF,20%,16V,GP,TP,5x11,5
C116 2401-002075 C-AL 4.7uF,20%,50V,GP,TP,5x11,5
C117 2401-000010 C-AL 220uF,20%,16V,GP,-,6.3x11mm,2.
C118 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,TP,2.3X3
C119 2201-000144 C-CERAMIC,DISC 100pF,5%,50V,CH,TP,8x3,5
C120 2201-000247 C-CERAMIC,DISC 15pF,5%,50V,CH,TP,5x3,5
C124 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,TP,2.3X3
C126 2401-000613 C-AL 1uF,20%,50V,WT,TP,5x11,5
C128 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,TP,2.3X3
C141 2201-000764 C-CERAMIC,DISC 82pF,5%,50V,NPO,TP,8x3.5,5
C142 2202-000654 C-CERAMIC,MLC-RADIAL 100nF,10%,50V,X7R,TP,5.1x6.6,5
C151 2401-000042 C-AL 100uF,20%,16V,GP,TP,6.3x7,5
C152 2202-000669 C-CERAMIC,MLC-RADIAL 10nF,10%,50V,X7R,TP,3.8x5.8,5.
C154 2202-002008 C-CERAMIC,MLC-AXIAL 10nF,+80-20%,50V,Y5V,TP,2.3X3.
C155 2401-000042 C-AL 100uF,20%,16V,GP,TP,6.3x7,5
C156 2401-000010 C-AL 220uF,20%,16V,GP,-,6.3x11mm,2
C157 2401-000603 C-AL 1uF,20%,50V,GP,TP,5x11,5
C158 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,TP,2.3X3
C161 2202-000669 C-CERAMIC,MLC-RADIAL 10nF,10%,50V,X7R,TP,3.8x5.8,5.
C162 2202-000669 C-CERAMIC,MLC-RADIAL 10nF,10%,50V,X7R,TP,3.8x5.8,5.
C163 2401-000443 C-AL 10uF,20%,25V,GP,TP,5x5mm,2mm
C166 2301-000004 C-FILM,PEF 2.2nF,5%,100V,TP,5.5X10X2.9,5m
C167 2401-002075 C-AL 4.7uF,20%,50V,GP,TP,5x11,5
C168 2401-000050 C-AL 10uF,20%,16V,GP,TP,5x11,2.5
C169 2401-000050 C-AL 10uF,20%,16V,GP,TP,5x11,2.5
C171 2201-000234 C-CERAMIC,DISC 150pF,5%,50V,CH,TP,9.5x3,5
7 Electrical Parts List
7-16 PG17**/PG19**/PG21**
Loc. No. Code No. Description Specification Remarks
7-2 Video PCB Parts
