7 Electrical Parts List
7-24 PG17**/PG19**/PG21**
17”,19”FST,S/L BNC Yes,No(main) Different Parts List
LOCATION PG****(WITH BNC) PG****(WITHOUT BNC)
code spec code spec
BNC ASSY' BH98-00076C NONE
(Auto Selection)
ZD245 - NONE 0403-000361 DIODE-ZENER,6.2V
ZD246 - NONE 0403-000361 DIODE-ZENER,6.2V
ZD247 - NONE 0403-000361 DIODE-ZENER,6.2V
ZD248 - NONE 0403-000361 DIODE-ZENER,6.2V
ZD249 - NONE 0403-000361 DIODE-ZENER,6.2V
ZD250 - NONE 0403-000361 DIODE-ZENER,6.2V
(Manual Selection)
CIS NONE BH39-00070A SIGNAL CABLE
CN203 3711-004351 CONNECTOR,16P,2.5MM ,ST - NONE
CN208 - NONE 3711-003843 CONNECTOR;BOX,8P,ST
(Auto Selection)
DB01 - NONE 0401-000005 DIODE-SWITCHING;1N4148
DB02 - NONE 0401-000005 DIODE-SWITCHING;1N4148
DG01 - NONE 0401-000005 DIODE-SWITCHING;1N4148
DG02 - NONE 0401-000005 DIODE-SWITCHING;1N4148
DR01 - NONE 0401-000005 DIODE-SWITCHING;1N4148
DR02 - NONE 0401-000005 DIODE-SWITCHING;1N4148
JP232 BH39-40305U JUMPER - NONE
JP233 - NONE BH39-40305U JUMPER
R118 - NONE 2001-000429 R-CF,1K,1/8W
RB01 - NONE 2001-000969 R-CARBON;75OHM,1/8W
RG01 - NONE 2001-000969 R-CARBON;75OHM,1/8W
RR01 - NONE 2001-000969 R-CARBON;75OHM,1/8W
(Manual Selection)
CN142 BH98-00079A ASSY,PCB/MISC-SN
CIS BH39-00058A 6P-7P 150mm HARNESS NONE
PEGASUS-FST BNC Yes,No(Video17”) Different Parts List
LOCATION PG17**(WITH BNC) PG17**(WITHOUT BNC)
code spec code spec
To Next Page
