7 Electrical Parts List
PG17**/PG19**/PG21** 7-25
PEGASUS-PJT BNC Yes,No(Video 19”) Different Parts List
LOCATION PG19**(WITH BNC) PG19**(WITHOUT BNC)
code spec code spec
(Auto Selection) WITH BNC WITHOUT BNC
C170 - NONE 2202-002009 C-CERAMIC,100NF,50V"
CG04 - NONE 2401-000597 C-AL,1UF,50V
DB01 - NONE 0401-000005 DIODE-SWITCHING;1N4148
DB02 - NONE 0401-000005 DIODE-SWITCHING;1N4148
DG01 - NONE 0401-000005 DIODE-SWITCHING;1N4148
DG02 - NONE 0401-000005 DIODE-SWITCHING;1N4148
DR01 - NONE 0401-000005 DIODE-SWITCHING;1N4148
DR02 - NONE 0401-000005 DIODE-SWITCHING;1N4148
JP161 - NONE BH39-40305U J/WIRE
Q103 - NONE 0501-000122 TR,2N3904
R116 - NONE 2001-000429 R-CF,1/8T,1K-J
R121 - NONE 2001-000734 R-CF,4.7K,1/8W
R122 - NONE 2001-000429 R-CF,1K,1/8W
R170 - NONE 2001-000429 R-CF,1K,1/8W
RG03 - NONE 2001-000995 R-CF,820ohm,1/8W
RB01 - NONE 2001-000969 R-CARBON;75OHM,1/8W
RG01 - NONE 2001-000969 R-CARBON;75OHM,1/8W
RR01 - NONE 2001-000969 R-CARBON;75OHM,1/8W
(Manual Selction)
CIS BH39-00094A 6P-7P 150MM HARNESS(EMI) NONE
PEGASUS-PJT BOM (SOG PCB) Auto Selection & Manual Selection Parts List
LOCATION PG19**(WITH BNC)
code spec
(ASS’Y CODE) BH98-00079A ASSY,PCB/MISC-SN
(Auto Selection)
CIS BH41-00036A PCB-SOG
HC01 2202-002008 C-MLC-AXIAL, 10nF,50V
HC02 2202-000841 C-CERAMIC,MLC, 33nF,100V
HC03 2202-002009 C-MLC-AXIAL, 100nF,50V
HD01 0401-000005 DIODE-SIG,1N4148
HIC01 1202-000119 C-LIN,LM319,COMPARATOR
HR01 2001-000734 R-AXIAL, REF-CF,4.7K,5%,1/6W
HR02 2001-000591 R-AXIAL, REF-CF,3.3K,5%,1/6W
HR03 2001-000325 R-AXIAL, REF-CF,120,5%,1/6W
HR04 2001-000449 R-AXIAL, REF-CF,2.2K,5%,1/6W
HR05 2001-000515 R-AXIAL, REF-CF,220,5%,1/6W
HR06 2001-000786 R-AXIAL, REF-CF,47K,5%,1/6W
HR07 2001-000786 R-AXIAL, REF-CF,47K,5%,1/6W
JP1 BH39-40305U JUMPER
(Manual Selection)
HCN01 3711-002702 CONNECTOR,4PIN
