7 Electrical Parts List
7-26 PG17**/PG19**/PG21**
(Auto Selection)
JP214 BH39-40305U CBF-HARNESS - NONE
JP267 - NONE BH39-40305U CBF-HARNESS
Q663 - NONE 0501-000586 TR-SMALLSIGNAL;KSC945
R290 NONE 2001-000221 R-CF,1.2KOHM,1/8W
R291 - NONE 2001-000007 R-CF,3KOHM,1/8W
R292 - NONE 2001-000812 R-CF,5.6KOHM,1/8W
R293 - NONE 2001-000221 R-CF,1.2KOHM,1/8W
R294 - NONE 2001-000007 R-CF,3KOHM,1/8W
R295 - NONE 2001-000812 R-CF,5.6KOHM,1/8W
R296 - NONE 2001-000331 R-CF,12KOHM,1/8W
R299 - NONE 2001-001107 R-CF(S),220ohm,1/2W
R662 - NONE 2001-000273 R-CARBON;100KOHM,1/8W
SW1 - NONE 3404-000244 SWITCH-TACT
SW2 - NONE 3404-000244 SWITCH-TACT
SW3 - NONE 3404-000244 SWITCH-TACT
SW4 - NONE 3404-000244 SWITCH-TACT
SW5 - NONE 3404-000244 SWITCH-TACT
CN201 3711-004182 CONNECTOR;BOX,10P - NONE
OP1 - NONE 0601-000334 LED,CBI-ANGLE, GRN/YEL
SW6 - NONE 3403-001075 SWITCH-PUSH,12V,0.1A
SW7 - NONE 3404-001079 2´Ü TACT S/W,4P
PJT 17” BASIC/OEM(main) Different Parts List
LOCATION PG17*S PG17*0
code spec code spec
To Next Page
