Compaq MV-920 User Manual

7 Electrical Parts List
7-28 PG17**/PG19**/PG21**
(Auto Selection)
C411 2301-001304 C-FILM,PPF;1.5nF,2.5KV 2303-001022 C-FILM,PPF;2nF,2.5KV
C412 2301-001169 C-FILM,PPF;1.8nF,2.5KV 2303-001022 C-FILM,PPF;2nF,2.5KV
C413 - NONE 2201-000469 C-CERAMIC,330PF,500V
C422 2301-000174 C-FILM,PEF;15nF,5%,100V 2301-000148 C-FILM,PEF;10nF,5%,100V
C451 2301-001249 C-FILM,MPPF;68nF,5%,400V 2306-000127 C-FILM,MPPF;120nF,5%,400V
C457 2301-001249 C-FILM,MPPF;68nF,5%,400V 2301-001273 C-FILM,MPEF;56nF,400V
R303 2004-000523 R-MF;200 OHM,1/4W 2004-000853 R-MF;390 OHM,1/4W
R304 2004-000532 R-METAL;20Kohm,1%,1/4W 2004-000412 R-METAL;18Kohm,1%,1/4W
R404 2001-000522 R-CARBON;22KOHM,5%,1/8W 2001-000411 R-CARBON;18KOHM,5%,1/8W
R420 - NONE 2003-000606 R-ETALOXIDE(S);270ohm,2W
R501 2001-000962 R-CARBON;75KOHM,5%,1/4W 2001-000084 R-CARBON;100KOHM,5%,1/4W
R636 2001-000226 R-CARBON;1.2ohm,1/2W 2001-000263 R-CARBON;1.8ohm,1/2W
(Manual Selection))
L403 BH26-00048A TRANS-H.LINEARITY BH26-00054A TRANS-H.LINEARITY
R405 2003-000473 R-METALOXIDE(S);10ohm,3W 2003-000763 R-METALOXIDE(S);6.8ohm,3W
R411 2003-000459 R-METALOXIDE(S);100ohm,3W 2003-000747 R-METALOXIDE(S);56ohm,3W
R412 2003-000459 R-METALOXIDE(S);100ohm,3W 2003-000747 R-METALOXIDE(S);56ohm,3W
R421 2006-001063 R-CEMENT;75OHM,5%,5W 2003-000653 R-METALOXIDE(S);330ohm,3W
CIS NONE BH39-40364Y PULSE TAPE
WARNING: 19 FST VIDEO 1P ASSY
1(PG19H*:BH39-00078A--150MM)
2(PG19L*:BH39-00090A--100MM)
(Auto Selection)
C451 2301-001273 C-FILM,MPEF;56nF,400V 2301-001249 C-FILM,MPPF;68nF,5%,400V
C457 2306-000224 C-FILM,MPEF;47nF,400V 2301-001249 C-FILM,MPPF;68nF,5%,400V
R303 2004-000940 R-MF;430 OHM,1/4W 2004-000790 R-MF;330 OHM,1/4W
R304 2004-000344 R-METAL;15Kohm,1%,1/4W 2004-004068 R-MF;19KOHM,1/4W
R305 2004-001254 R-METAL;8.2Kohm,1%,1/4W 2004-000216 R-MF;10KOHM,1/4W
R561 2001-000890 R-CF,6.8K,1/8W 2001-000812 R-CF,5.6K,1/8W
R562 2001-000241 R-CF,1.5K,1/8W 2001-000221 R-CF,1.2K,1/8W
(Maunal Selection)
R410 2006-001069 R-CEMENT,2.2ohm,5W 2006-001070 R-CEMENT,1.8ohm,5W
R411 2006-001071 R-METALOXIDE(S);56ohm,5W 2006-000195 R-METALOXIDE(S);51ohm,5W
R412 2006-001071 R-METALOXIDE(S);56ohm,5W 2006-000195 R-METALOXIDE(S);51ohm,5W
PJT 19” (FST) CDT (main) Different Parts List
LOCATION PG19** TSB:BH03-00029A PG19** SDD:BH03-00030A
code spec code spec
PJT 19” S/L(main) Different Parts List
LOCATION PG19** MEC:BH03-00001A PG19** SDD:BH03-00047A
code spec code spec
