7 Electrical Parts List
PG17**/PG19**/PG21** 7-29
PEGASUS - PROJECT MODEL CDT CODE NO
MODEL PG17HS PG17HO
CDT MAKER TSB SDD
CDT CODE BH03-10339L BH03-10339A
MODEL PG19HS PG19HO PG19LS PG19LO
CDT MAKER TSB TSB TSB SDD
CDT CODE BH03-00029A BH03-00029A BH03-00030A BH03-00030A
MODEL PG19SS PG19SO PG19RS PG19RO
CDT MAKER MEC SDD SDD SDD
CDT CODE BH03-00001A BH03-00047A BH03-00047A BH03-00047A
LOCATION PG17**(FST) TDB:BH03-10339L PG19*S(FST) TSB:BH03-00029A
code spec code spec
C272 2201-000532 C-CERAMIC,4.7NF,50V 2201-000017 C-CERAMIC,1NF,50V
C306 2401-000852 C-AL,220UF,35V,85¡É 2401-000852 C-AL,220UF,35V,85¡É
C311 2401-000039 C-AL,1000UF,16V,85¡É 2401-000039 C-AL,1000UF,16V,85¡É
C402 2401-000046 C-AL,10UF,250V,85¡É 2401-000046 C-AL,10UF,250V,85¡É
C411 2303-001022 C-FILM,PPF;2nF,2.5KV 2301-001304 C-FILM,PPF;1.5nF,2.5KV
C412 2303-001022 C-FILM,PPF;2nF,2.5KV 2301-001169 C-FILM,PPF;1.8nF,2.5KV
C413 2201-000469 C-CERAMIC,330PF,500V - NONE
C417 2201-000012 C-CERAMIC,220PF,1KV - NONE
C418 2301-000519 C-FILM,3.3NF,100V 2301-000102 C-FILM,1.2NF,100V
C422 2301-000005 C-FILM,PEF;33nF,5%,100V 2301-000174 C-FILM,PEF;15nF,5%,100V
C451 2306-000127 C-FILM,MPPF;120nF,5%,400V 2301-001249 C-FILM,MPPF;68nF,5%,400V
C452 2306-000127 C-FILM,MPPF;120nF,400V 2301-001259 C-FILM,MPPF;100nF,400V
C457 2306-001011 C-FILM,MPEF;56nF,250V 2301-001249 C-FILM,MPPF;68nF,5%,400V
C527 2401-000971 C-AL,22UF,50V 2401-001195 33uF,20%,50V
C530 2201-000469 C-CERAMIC,330PF,500V 2201-000469 C-CERAMIC,330PF,500V
C551 2401-000043 C-AL,1UF,160V,85¡É 2401-000043 C-AL,1UF,160V,85¡É
CIS BH41-00027A PCB-MAIN,330*247mm BH41-00027A PCB-MAIN,330*247mm
CN416 - NONE - NONE
CN417 - NONE - NONE
JP214 BH39-40305U CBF-HARNESS BH39-40305U CBF-HARNESS
JP267 - NONE - NONE BH39-40305U
JP444 BH39-40305U JUMPER BH39-40305U JUMPER
L405 - NONE - NONE
Q663 - NONE - NONE
R290 NONE - NONE
R291 - NONE - NONE
R292 - NONE - NONE
PJT BOM(main) Different Parts List
(Auto Selection)
