Compaq MV-920 User Manual

7 Electrical Parts List
7-30 PG17**/PG19**/PG21**
LOCATION PG17**(FST) TDB:BH03-10339L PG19*S(FST) TSB:BH03-00029A
code spec code spec
R293 - NONE - NONE
R294 - NONE - NONE
R295 - NONE - NONE
R296 - NONE - NONE
R299 - NONE - NONE
R301 2004-000532 R-METAL;20Kohm,1%,1/4W 2004-000344 R-METAL;15Kohm,1%,1/4W
R302 2004-000481 R-METAL, 2.4Kohm,1%,1/4W 2004-000679 R-METAL, 2Kohm,1%,1/4W
R303 2004-002234 R-MF;560 OHM,1/4W 2004-000523 R-MF;200 OHM,1/4W
R304 2004-000412 R-METAL;18Kohm,1%,1/4W 2004-000532 R-METAL;20Kohm,1%,1/4W
R305 2004-001211 R-METAL;7.5Kohm,1%,1/4W 2004-001254 R-METAL;8.2Kohm,1%,1/4W
R404 2001-000563 R-CARBON;27KOHM,5%,1/8W 2001-000522 R-CARBON;22KOHM,5%,1/8W
R410 2003-000557 R-METAL OXIDE(S), 2.2ohm,3W 2003-000557 R-METAL OXIDE(S),2.2ohm,3W
R415 2001-000281 R-CF,100ohm,1/8W 2001-000515 R-CF,220ohm,1/8W
R420 2003-000578 RES-MO,220ohm,5%,2W(S) - NONE
R476 2001-000022 R-CF,33ohm,1/2W 2001-000022 R-CF,33ohm,1/2W
R501 2001-000962 R-CARBON;75KOHM,5%,1/4W 2001-000962 R-CARBON;75KOHM,5%,1/4W
R526 2001-000008 15KOHM,5%,1/8W 2001-000812 5.6KOHM,5%,1/8W
R561 2001-000890 R-CF,6.8K,1/8W 2001-000890 R-CF,6.8K,1/8W
R562 2001-000241 R-CF,1.5K,1/8W 2001-000241 R-CF,1.5K,1/8W
R633 2001-001106 R-CF(S),220K,1/2W 2001-001106 R-CF(S),220K,1/2W
R635 2001-001106 R-CF(S),220K,1/2W 2001-001106 R-CF(S),220K,1/2W
R636 2001-000226 R-CARBON;1.2ohm,1/2W 2001-000226 R-CARBON;1.2ohm,1/2W
R648 2001-001106 R-CF(S),220K,1/2W 2001-001106 R-CF(S),220K,1/2W
R662 - NONE - NONE 2001-000273
SW1 - NONE - NONE
SW2 - NONE - NONE
SW3 - NONE - NONE
SW4 - NONE - NONE
SW5 - NONE - NONE
(Manual Selection)
CIS - NONE BH39-00078A 150MM,WIRE ASS'Y
CN201 3711-004182 CONNECTOR;BOX,10P 3711-004182 CONNECTOR-HEADER;BOX,10P
CN409 3711-000197 CONNECTOR-MOLEX;BOX,3P 3711-000885 CONNECTOR-JST;BOX,3P
HS402 BH99-10057C H/S ASS'Y, 2SC5583/D10U150S BH99-10057C H/S ASS'Y 2SC5583/D10U150S
HS409 BH99-10059M H/S ASS'Y, SKS10N20*4 BH99-10059M H/S ASS'Y, SKS10N20*4
HS508 BH99-10019F H/S ASS'Y,TIP29C BH99-10019F H/S ASS'Y,TIP29C
HS60 BH99-10019N H/S ASS'Y,31DF6 BH99-10019N H/S ASS'Y,31DF6
HS602 - NONE - NONE
L403 BH26-00001A TRANS-H.LINEARITY BH26-00048A TRANS-H.LINEARITY
L521 BH27-00018A COIL-CHOKE,6.8UH BH27-00018A COIL-CHOKE,6.8UH
L601 BH27-00025A LINE FILTER BH27-00025A LINE FILTER
OP1 - NONE - NONE
R405 2003-000763 R-METALOXIDE(S);6.8ohm,3W 2003-000473 R-METALOXIDE(S);10ohm,3W
R411 2003-000747 R-METALOXIDE(S);56ohm,3W 2003-000459 R-METALOXIDE(S);100ohm,3W
R412 2003-000747 R-METALOXIDE(S);56ohm,3W 2003-000459 R-METALOXIDE(S);100ohm,3W
