Compaq MV-920 User Manual

7 Electrical Parts List
PG17**/PG19**/PG21** 7-31
LOCATION PG19**(S/L) MEC:BH03-00001A
code spec
C272 2201-000017 "C-CERAMIC,1NF,50V"
C306 2401-000856 "C-AL,220UF,35V,105¡É"
C311 2401-000142 "C-AL,1000UF,16V,105¡É"
C402 2401-001872 "C-AL,10UF,250V,105¡É"
C411 2303-001022 "C-FILM,PPF;2nF,2.5KV"
C412 2303-001022 "C-FILM,PPF;2nF,2.5KV"
C413 2201-000019 " C-CERAMIC,10nF,500V"
C417 - NONE
C418 2301-000102 "C-FILM,1.2NF,100V"
C422 2301-000148 "C-FILM,PEF;10nF,5%,100V"
C451 2301-001273 "C-FILM,MPEF;56nF,400V"
C452 2301-001259 "C-FILM,MPPF;100nF,400V"
C457 2306-000224 "C-FILM,MPEF;47nF,400V"
C527 2401-001195 "33uF,20%,50V"
C530 2201-000012 "C-CERAMIC,220PF,1KV"
C551 2401-000055 "C-AL,1UF,160V,105¡É"
CIS BH41-00037A "PCB-MAIN,320*247mm"
CN416 BH71-40300A PIN-HINGE
CN417 BH71-40300A PIN-HINGE
JP214 - NONE
JP267 BH39-40305U CBF-HARNESS
JP444 - NONE
L405 2701-000179 "INDUCTOR,33UH"
Q663 0501-000586 TR-SMALLSIGNAL;KSC945
R290 2001-000221 "R-CF,1.2KOHM,1/8W"
R291 2001-000007 "R-CF,3KOHM,1/8W"
R292 2001-000812 "R-CF,5.6KOHM,1/8W"
R293 2001-000221 "R-CF,1.2KOHM,1/8W"
R294 2001-000007 "R-CF,3KOHM,1/8W"
R295 2001-000812 "R-CF,5.6KOHM,1/8W"
R296 2001-000331 "R-CF,12KOHM,1/8W"
R299 2001-001107 "R-CF(S),220ohm,1/2W"
R301 2004-000616 "R-METAL;24Kohm,1%,1/4W"
R302 2004-000728 "R-METAL, 3.9Kohm,1%,1/4W"
R303 2004-000940 "R-MF;430 OHM,1/4W"
R304 2004-000344 "R-METAL;15Kohm,1%,1/4W"
NO LOCATION PG19**(S/L) MEC:BH03-00001A
code spec
39 R410 2006-001069 R-CEMENT,2.2ohm,5W(πö»›)
40 R415 2001-000515 R-CF,220ohm,1/8W
41 R420 2003-000650 RES-MO,330,5%,2W
42 R476 2003-000661 R-MO(S),33ohm,2W
43 R501 2001-000115 R-CARBON;82KOHM,5%,1/4W
44 R526 2001-000812 5.6KOHM,5%,1/8W
46 R561 2001-000890 R-CF,6.8K,1/8W
47 R562 2001-000241 R-CF,1.5K,1/8W
48 R633 2001-001106 R-CF(S),220K,1/2W
49 R635 2001-001113 R-CF(S),270K,1/2W
50 R636 2003-000446 MOR,2W,1.8ohm
51 R648 2001-001113 R-CF(S),270K,1/2W
52 R662 2001-000273 R-CARBON;100KOHM,1/8W
53 SW1 3404-000244 SWITCH-TACT
54 SW2 3404-000244 SWITCH-TACT
55 SW3 3404-000244 SWITCH-TACT
56 SW4 3404-000244 SWITCH-TACT
57 SW5 3404-000244 SWITCH-TACT
(Manual Selection)
2 CIS NONE
3 CN201 - NONE
6 CN409 3711-000434 CONNECTOR-JST;2P
8 HS402 BH99-10057A H/S ASS'Y, 2SC5584/D10U150S
9 HS409 BH99-10059L H/S ASS'Y,10N20*2/19N20*2
10 HS508 BH99-10021K H/S ASS'Y,TIP29C(H/S ‹Àº°Í)
11 HS60 BH99-00005E H/S ASS'Y,31DF6(H/S ‹Àº °Í)
12 HS602 BH99-10047C DIODE,BRIDGE,D3SB60
13 L403 BH26-30338W TRANS-H.LINEARITY
14 L521 BH27-00027A COIL-CHOCK, 6.5uH
15 L601 BH27-00026A LINE FILTER
16 OP1 0601-000463 LED;ROUND,G/O
17 R405 2003-000763 R-METALOXIDE(S);6.8ohm,3W
18 R411 2006-001071 R-METALOXIDE(S);56ohm,5W
19 R412 2006-001071 R-METALOXIDE(S);56ohm,5W
20 R421 2003-000695 R-METALOXIDE(S);430ohm,3W
21 SW6 3403-001075 SWITCH-PUSH
22 SW7 3404-001079 SWITCH-TACT
LOCATION PG17**(FST) TDB:BH03-10339L PG19*S(FST) TSB:BH03-00029A
code spec code spec
R421 2003-000653 R-METALOXIDE(S);330ohm,3W 2006-001063 R-CEMENT;75OHM,5%,5W
SW6 - NONE - NONE
SW7 - NONE - NONE
T601 BH26-00039A TRANS-POWER, 150UH,18P BH26-00039A TRANS-POWER, 150UH,18P
C604 2301-001285 C-FILM,MPPF:680nF,275V,BK 2301-001285 C-FILM,MPPF:680nF,275V,BK
C609 2401-003483 400V,270uF 2401-003483 400V,270uF
(Auto Selection)
