7 Electrical Parts List
7-32 PG17**/PG19**/PG21**
LOCATION PG19**(S/L) MEC:BH03-00001A
code spec
R305 2004-001254 "R-METAL;8.2Kohm,1%,1/4W"
R404 2001-000679 R-CARBON;36KOHM,5%,1/8W
R410 2003-000557 R-METAL OXIDE(S), 2.2 ohm
R415 2001-000281 R-CF, 100ohm, 1/8W
LOCATION PG19**(S/L) MEC:BH03-00001A
code spec
T601 BH26-00050A TRANS-POWER,130UH,EER4445
C604 2305-001049 C-FILM,MPPF:1uF,275V,BK
C609 2401-001137 400V,330uF
21” Different Parts List
LOCATION PG21**(FST)
code spec
(Auto Selection)
JP214 BH39-40305U CBF HARNESS 52MM,AWG22(0.6PI)
JP267 BH39-40305U CBF HARNESS 52MM,AWG22(0.6PI)
LOCATION PG21** HTC:BH03-00055A
code spec
(Auto Selection)
C411 2301-001240 C-FILM,PPF 2.5nF,5%,3KV,BK,29x23x13,20
C412 2301-001240 C-FILM,PPF 2.5nF,5%,3KV,BK,29x23x13,20
C413 »èÁœ
C422 2301-000174 C-FILM,PEF 15nF,5%,100V,TP,7.2x4.0x7.5mm,
C451 2306-000127 C-FILM,MPPF 120nF,5%,400V,TP,21.5x17mm,5mm
C457 2306-000119 C-FILM,MPPF 100nF,5%,250V,TP,19x14.5x6.5,7
R303 2004-000334 R-METAL 150ohm,1%,1/4W,AA,TP,2.4x6.4mm
R304 2004-000412 R-METAL 18Kohm,1%,1/4W,AA,TP,2.4x6.4mm
R404 2001-000522 R-CARBON 22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R420 »èÁœ
R501 2001-000563 R-CARBON 27KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R636 2001-000016 R-CARBON(S) 1OHM,5%,1/2W,AA,TP,2.4X6.4MM
(Manual Selection)
L403 BH26-00062A TRANS-H.LINEARITY 49MH/3.5UH,5PIN,DR1420*2,YL-81(C:6.0),49.0MH/3.5UH,-,-
R405 2003-000473 R-METAL OXIDE(S) 10ohm,5%,3W,AA,TP,6x16mm
R411 2003-002142 R-METAL OXIDE(S) 62OHM,5%,3W,AA,TP,5.5X16MM
R412 2003-002142 R-METAL OXIDE(S) 62OHM,5%,3W,AA,TP,5.5X16MM
R421 2006-001063 R-CEMENT 75OHM,5%,5W,CA,BK,9.5X22X9.5MM
