1–34 Maintenance and Service Guide
Product Description
The Evo Notebook N620c, N610c, N610v, and N600c right side
and rear panel components are shown in Figure 1-3 and described
in Table 1-6.
Figure 1-3. Right Side and Rear Panel Components—
Evo Notebook N620c, N610c and N610v
Table 1-6
Right Side and Rear Panel Components
Item Component Function
1 DC power jack Connects any one of the following:
AC adapter
Optional automobile power
adapter/charger
Optional aircraft power adapter
2 Keyboard/mouse
connector
Connects an external keyboard or
PS/2-compatible external mouse. To
connect a keyboard and a mouse at the
same time, use an optional Y-adapter.
