Product Description
Maintenance and Service Guide 1–35
3 Parallel connector Connects a parallel device.
4 USB connectors (2) Connect USB devices.
5RJ-45 jack
(network models only)
Connects the network cable. A network
cable is not included with the notebook.
6 Serial connector Connects a serial device.
7 External monitor
connector
Connects an external monitor or overhead
projector.
8 S-Video connector Connects a television, VCR, camcorder, or
overhead projector.
9 Vent Allows airflow to cool internal components.
Ä
To prevent damage, the notebook
shuts down if an overheating
condition occurs. Do not block the
cooling vent. Avoid placing the
notebook on a blanket, rug, or other
flexible surface that may cover the
vent area.
10 Hard drive Supports the removable primary hard drive.
11 PC Card slots Support a 32-bit (CardBus) or 16-bit
PC Card.
12 PC Card eject buttons Eject a PC Card from a PC Card slot.
Table 1-6
Right Side and Rear Panel Components
(Continued)
Item Component Function
