1–36 Maintenance and Service Guide
Product Description
The Evo Notebook N600c right side and rear panel components
are shown in Figure 1-4 and described in Table 1-7.
Figure 1-4. Right Side and Rear Panel Components—
Evo Notebook N600c
Table 1-7
Right Side and Rear Panel Components
Item Component Function
1 MultiPort Connects wireless communication devices,
such as an optional Bluetooth or 802.11b
MultiPort module, and other options.
2 DC power jack Connects any one of the following:
■ AC adapter
■ Optional automobile power
adapter/charger
■ Optional aircraft power adapter
