Product Description
Maintenance and Service Guide 1–37
3 Keyboard/mouse
connector
Connects an external keyboard or
PS/2-compatible external mouse. To
connect a keyboard and a mouse at the
same time, use an optional Y-adapter.
4 Parallel connector Connects a parallel device.
5 Docking connector Connects the computer to the optional
expansion base, convenience base, or port
replicator.
6 Serial connector Connects a serial device.
7 External monitor
connector
Connects an external monitor or overhead
projector.
8 S-Video connector Connects a television, VCR, camcorder, or
overhead projector.
9RJ-45 jack (network
models only)
Connects the network cable. A network
cable is not included with the computer.
10 USB connectors (2) Connect USB devices.
11 Vent Allows airflow to cool internal components.
Ä
To prevent damage, the notebook
shuts down if an overheating
condition occurs. Do not block the
cooling vent. Avoid placing the
notebook on a blanket, rug, or other
flexible surface that may cover the
vent area.
12 Hard drive Supports the removable primary hard drive.
13 PC Card slots Support 32-bit (CardBus) or 16-bit PC
Cards.
14 PC Card eject buttons Eject PC Cards from the PC Card slots.
Table 1-7
Right Side and Rear Panel Components
(Continued)
Item Component Function
