1–38 Maintenance and Service Guide
Product Description
The Evo Notebook N620c, N610c, and N610v bottom
components are shown in Figure 1-5 and described in Table 1-8.
Figure 1-5. Bottom Components—Evo Notebook N620c,
N610c, and N610v
Table 1-8
Bottom Components
Item Component Function
1 Media Bay Accepts a diskette drive, CD- or DVD-ROM
drive, or secondary battery pack.
2 Media Bay release latch Releases the Media Bay device from the
connector.
