REMOVAL & REPLACEMENT
Removing the Power Supply/Fan Assembly, continued
Removal
6
With the Drive Cage Assembly lying on a flat
surface, (1 ) remove one screw located on
the side of the fan, (2) slide the Power
Supply/Fan Assembly upward, and pull from
the drive cage slots.
Replacement
To replace the power supply/fan
assembly, reverse this procedure.
