REMOVAL & REPLACEMENT
Preparation for Disassembly
To prepare the computer for removal and replacement procedures, complete the following steps:
1
Remove any diskette, compact disc, or tape from the computer.
2
Turn off the computer and any peripheral devices that are connected to the
computer.
CAUTION: The computer power switch should
be turned off before you disconnect any cables.
3
Disconnect the power cord from the electrical outlet, and then from the
computer.
4
Disconnect all peripheral device cables from the computer.
IMPORTANT: During disassembly, label each cable as you remove
it. Be sure to note its position and routing.
