REMOVAL & REPLACEMENT
Removing the Memory Module (DIMM)
1
Perform preparation
procedures.
2
Remove the Right Easy
Access Panel.
3
Pull out on the (1)
retention clips of the
socket and (2) unplug
the DIMM from the
system board .
Replacing the DIMM
Next Step
