REMOVAL & REPLACEMENT
Removing the Top Access Cover
Removal
1
Perform preparation procedures.
2
Remove the Left Easy Access
panel.
3
Lift the top access cover off the
hinges on the chassis.
Replacement
To replace the top access cover,
reverse this procedures.
