REMOVAL & REPLACEMENT
Removing the Speaker Assembly
Removal
1
Perform preparation
procedures.
2
Remove the Left Easy Access
panel.
3
Remove the top access cover.
4
Remove the LCD display board.
5
Disconnect the Speaker Cable
from the LCD Board.
Next Step
