VII.4 : Technical chart
Bridge or water level contact11
Bridge or water level contact10J4
Key switch STOP9
Common8
Push button OPEN7
Push button CLOSE6J3
Sensor signal5
Sensor +4
Sensor -3
Brake
2
Brake
1J2
Motor + or -M2
Motor + or -M1J1
Connector relay card 2Relay2
Connector relay card 1Relay1
Connection receiver print remote controlRemote 1
Use flexible wires !Min. 2 x 4 mm²CABLE4
Use flexible wires !Min. 5 x 0,75 mm² shieldedCABLE3
Use flexible wires !Min. 4 x 0,75 mm²CABLE2
Use flexible wires !Min. 3 x 1,5 mm²CABLE1
DescriptionCode
